Quick Details

  • Type: Digital Printer
  • Condition: New
  • Plate Type: Solvent Printer
  • Place of Origin: Liaoning, China (Mainland)
  • Brand Name: Zhongye
  • Model Number: ZY-SK3200H
  • Usage: Paper Printer, outdoor advertising media
  • Automatic Grade: Automatic
  • Color & Page: Multicolor
  • Voltage: 220V
  • Gross Power: 2500W
  • Dimensions(L*W*H): 5.2m*1.4m*1.5m
  • Weight: 1500KG/2200KG
  • Certification: CE.ISO
  • After-sales Service Provided: Engineers available to service machinery overseas
  • Coulour: 4 or6 colour: Maximum print width:3.2m
  • Rsolution:1440dpi: Net weight:1100kg
  • Print head: Seiko510 or Seiko1020: Certification: CE ISO ..

Packaging & Delivery

Packaging Details standard wooden case
Delivery Time 15 days after receive the deposit

3.2m Solvent Printer: adopting SPT and Xaar series printheads. Locating mode is combined with DC motor and raster. This kind of printer is widly used for outdoor printing.It will be your first choice of high-speed & high-resolution



ZY-3200H print head:Seiko510  or Seiko1020     print head qty:4pcs,6pcs,8pcs,12pcs,      resolution:1440dpi




Configuration below is according to different models:
Motor: Japanese Panasonic, Fuji AC servo motor;
Rail:Japanese THK,Tawinese HWIN;
Heating system:front&back double heating;
Feed-in&take-up system:IR controlled auto feed-in&take-up system;
Printhead cleaning system: positive pressure, vaccum
Ink system:German KNF ink supply system,Japanese negative pressure system



The  technical parameter

 Model

ZY-SK3200H

 Print technology drop-on-demand Piezo electric
 Printhead 4/6/8/12(SPT510/SPT1020)
 Print width 3.2m
 Resolution 1440 dpi max
 speed 2pass 120sqm/h ; 4pass 60sqm/h ; 6pass 40sqm/h(4/6 heads,half speed)
 locating mode raster/servo
 colour CMYK LC LM
 media with 3.20m
 Media handle roll to roll
 Media types

Flex banner,vinyl sheet,one way vision,mesh,

PVC fabrics,paper,etc

 InkSolvent/two-year outdoor lifetime
 File formatTIFF,JPEG,Postscript 3,EPS,PDF
 Working process

Printmon software for windows xp

 Rip

Photoprint /maintop

 Power supply

50hz/60hz 220v(10%)20A

 Operation environment

(Temperature )18-26(Humidity )40%-70%

 Size 5.2M*1.4M*1.5M
 Weight1100/1500KG
Usage:Flex banner,vinyl sheet,one way vision,mesh, PVC fabrics,paper,etc

Warranty:
1. one year warranty for parts ( not including head and ink supply system)
2. 24 hours online technical support,
3. lifetime maintain
4. offer engineer man to your country to help client anytime if request

5with CE certificat


The different model for your choice
Solvent PrinterZY-2000ZY-2500ZY-3200ZY-3200HZY-5300ZY-6800
Weight450kg470kg550kg1100kg1500kg1800kg
Print Size2m2.5m3.2m3.2m5m6.8m
machine's  size3.4m*0.7m*1.4m3.9m*0.7m*1.4m4.6m*1.7m*1.4m5.2m*1.2m*1.5m7.2*1.4*1.7m8.8m*1.4m*1.5m





If you have any requirement,just contact me freely



Contact Person: Rose Zhou

Mobile: 0086 13478324856

Skype: rainbowzhou2006
