Quick Details

  • Type: Digital Printer
  • Condition: New
  • Plate Type: Flatbed Printer
  • Place of Origin: Liaoning, China (Mainland)
  • Brand Name: Zhongye
  • Model Number: SP2516
  • Usage: glass,ceramic,metal,leather,wood,KT board, PVC board,ABS board, and so
  • Automatic Grade: Automatic
  • Color & Page: Multicolor
  • Voltage: 220-240V
  • Gross Power: 3500w
  • Dimensions(L*W*H): 3.8m*1.6m*1.4m
  • Weight: 1000kg
  • Certification: CE,ISO
  • After-sales Service Provided: Engineers available to service machinery overseas
  • Print head:PQ512: the colour:CMYK+ W
  • drying system:UV/LED lamp: The weight:1000KG

Packaging & Delivery

Packaging Details wood package
Delivery Time 10 days after receive the deposit



Technical Parameter:

Spectra UV Flatbed

SP 2516

SP3018

SP3520

Printing Technolgoy

Drop-on-demand Piezo Electric

Head Quantity

4/5/6/7/8(Polaris 512/15pl)

4/5/6/7/8(Polaris 512/15pl)

4/5/6/7/8(Polaris 512/15pl)

Printing Size

Max 2.50m*1.60m

Max 3.00*1.80m

Max 3.50m*2.00m

Printing Height

Max 10cm

Resolution

1440 DPI

Speed

4 pass 60m2/h

6 pass 40m2/h

8 pass 30m2/h

Locating Mode

Raster/Servo



4 pcs of Head: K C M Y

5 pcs of Head: K C M Y + W

6 pcs of Head: K C M Y + W+V/6 pcs of Head: K C M Y + W+W

7 pcs of Head: K C M Y  L-C L-M + W

8 pcs of Head: K C M Y  L-C L-M + W+V

Media Width

2.5m*1.6m

3.2m*1.8m

3.8m*2.1m

Dimension

4.6m*2.3m*1.65m

5.2m*2.3m*1.65m

5.8m*2.3m*1.65m

Weight

1200KG

1600KG

1800KG

Parameter can be changed without notice.





ZhongYe Spectra Polaris UV Flatbed Printer:

 1.Adopting Polaris 15pl all-steel printhead. Each head 512 nozzles.Head ignition frequency 30-50K,

speed 2~4 times of similar products, printing speed can reach 60m2/h when 4 heads working.



2.Use imported guide rail, high precision Stepping system, all-steel flatbed.Sucktion device inside to

make media no wrinkling and ensure perfect output quality; Positive and negative pressure cleaning

system achieve full-automatic printhead cleaning;Individual purging ink system  to save ink.;

Tee coupling function and moisturizing device effectively protect the printheads and head  longer life.

White ink stirring.



3.Double Mercury lamps  make best ink curing result.



4.UV ink outdoor life span 5 years.





What can be printed?

KT board;PVC board;Plexiglass board;glass board;ceramic board;tile;metal board;leather etc all flat media



Application:

Decration Industry;Glass Indurstry;Sign Industry;Exhibition Industry;Rigid Paperboard Packing Industry;Lether;
Textile Printing Industry;Artware Industry;Furniture Industry etc.



After-sales-service:

1.One year warranty and technician available overseas.

2.Free to change all the spares except easily broken spares like printhead, ink supplying system

3.Free training and free printer installing, but need afford accommodation&air ticket&visa if serve on site

4.Online after-sales-serive by Email,Skpye,QQ,MSN,phone etc with English speaking engineer



Company Introduction:

Liaoning ZhongYe technology and industry Development Co., Ltd is one of the leading manufacturers  in China,

which dedicates all its strength to produce and distribute digital printing machines, outdoor printing media,

indoor inkjet printing media etc. Our company has 216 office workers, with strong technology research

and development team, including four electronic engineers, two software engineers, twelve mechanical engineers,

six test engineers, etc. The company, with 35,000 square meters production lines and over RMB50 million investments,

is located inthe Shenyang City of old  industrial bases of china, near Dalian port of huge international sea port.

Over 2000 printing  equipment is launched and RMB 300 million incomes are carried out per year.





Working Video Link:

https://youtu.be/loP93se54Ao
