UV roll to roll printer

FOB Reference Price:Get Latest Price
$10,000.00 - $25,000.00 / Sets | 1 Set/Sets (Min. Order)
Gross Power:
2000W
Report Suspicious Activity
Overview
Quick Details
After-sales Service Provided:
Online support, Engineers available to service machinery overseas
Color & Page:
MULTICOLOR
Certification:
CE SGS
Plate Type:
rool to roll print
Condition:
New
Place of Origin:
Liaoning, China (Mainland)
Brand Name:
ZHONGYE
Dimensions(L*W*H):
5.4mx1mx1.7m & 7.85mx2mx2.13m
Weight:
2250KG
Automatic Grade:
Automatic
Voltage:
220-240V
Warranty:
1 Year
Print Dimension:
5.2mX0.95mX1.7m
Ink Type:
solvent ink
Print size:
3.2 m & 5m
Product Model:
UVB2513G,2513K,3020G,3020K
Ink color:
C M Y K LC LM W V
Ink type:
CBF UV-H01 Ink
Drying system:
UV Led
Supply Ability
Supply Ability:
1000 Set/Sets per Year
Packaging & Delivery
Packaging Details
packed in poly wooden box specially for the printers and the box is free from fumigation
Port
Dalian port
Product Description

Product Application:

Digital UV roll to roll Printer For Sale,Choose the TOP parts of the world
The digital UV roll to roll Printer is the latest UV machine of Zhongye company . This model is designed for industrial bulk production with high printing speed,which can print on almost any material directly .With UV light irradiatingduring printing procedure, images on object surface are dry fast and Scratch resistance .
It replaces the traditional screen printing technology, and brings to customers the individualized, small-lot, various, and multicolored products, with the output features of speediness, high efficiency and flexibilit.


Product types can available:

1)Flatbed printer
2)Roll to roll printer
3)Multi functional printer


UV Flatbed printer applications:
--Decoration industry
--Glass, Ceramic industry;
--Advertising & Sign industry;
--Furniture and personalized products etc


UV Flatbed printer media :
--Class acrylic wood sheet.
--Ceramic metal sheet PVC board.
--Corrugated plate plastic etc.
--Almost everything with flat surface .

Specifications of High Capacity UV roll to roll Printer
Type
UVB2513G
UVB2513K
UVB3020G
UVB3020K
Printing Technology
Intelligent variable ink drops technology,grey scale print technology.
Print head Number
Ricoh GEN5 double color print head 2*640 1280 nozzles(Konica1024i 4/6/8pcs)
Max.Print Size
3.2m
3.2m
5m
5m
Print Height
8 cm
Resolution
1200x1200DPI 7-21pl variable ink drops,photo degree output quality,minimum 2pt letter
Fast Mode
4 pass: 48sqm/h
4 pass: 64sqm/h
4 pass: 50sqm/h
4 pass: 68sqm/h
Production Mode
6 pass: 36sqm/h
6 pass: 48sqm/h
6 pass: 38sqm/h
6 pass: 51sqm/h
Quality Mode
8 pass: 24sqm/h
8 pass: 32sqm/h
8 pass: 25sqm/h
8 pass: 34sqm/h
Ink Model
CBF UV-S01 Ink
Ink Color
C M Y K LC LM W V
Vacuum Table
Hard oxydic vaccum adsorption platform,mechanical drive
Drying System
UV LED
Working Process
Printmon software for windows 7/windows 8
Data Port
3.0 USB
File Format
Adobe Postscript Level 3,PDF,JPEG,TIFF,EPS,AI
RIP
Maintop/Photoprint/printfactory
Electric Supply
Two phase electric ,220V AC,50/60Hz,20V 4.5KW
Environment temperature
20 - 25 ℃
Relative Humidity
40% -70%
Dimension
5.4m x 1m x 1.7m
5.4m x 1m x 1.7m
7.85m x 2m x 2.13m
7.85m x 2m x 2.13m
Table Height
1.05 m
1.05 m
1.45 m
1.45 m
Weight
2250kg
2250kg
5850kg
5850kg
Media
Backlit banner.adhesive vinyl,coated flex banner . PET, Transparent film, soft film.3P cloth.
wall paper,leather. non-woven cloth. and all the other roll to roll materials

Main Features:

1.Equipped with Imported EPSON heads with 180 nozzles 8 channels
2.With 2 heas for high speed and high quality.
3.6sqm/hr-12sqm/hr ( White and color printing at the same time), if you only print color, the printing speed will be faster for production printing with 12-24sqm/hr
4.Fast fiber transmission technology.
5.White ink circulation system to avoid white ink precipitating.
6.6 zones vacuum suction platform for easy operation and save energy.
7.Long-lasting UV LED lamps are safe, energy efficient and generate minimum heat.
8.Double guide are used for a stable and precise movement.
9.All steel frame structure.-Best Industrial frame, the printhead can upgrade.
10.Secondary ink supply system. 11.operation platform 12.water-cooling circulation system 13.automatic alarm

Certifications
Our Company
After-sales Service

1.One year warranty and technician is available overseas.lifetime maintainence for printer.

2.Free to change all the spaces except easily broken spares like printhead,ink supplying system etc.
3.Free training and free printer installing,but need afford accmmodation & air tickets & visa if serve on site.
4.Provide one set ink free and one free spare parts with printer together.
5.Free software update for client in the future if needed.
6.Online after sales service by Email,Skype,Wechat,Whatsapp ,phone etc with English speaking engineer.
